CNC Lathe w/ Y-axis - 8 in. chuck
|
NT-208Y
Y-Axis Lathe
The NT-208Y is Campro’s highly flexible and profitable CNC Turning Center
High performance heavy duty box guideways, 30 Degree cast iron inclined bed to ensure quick chip evacuation.
Our NT-208Y series CNC Turning Center is based on a high quality cast iron bed for superior rigidity and anti-vibration characteristics.
30 degree cast iron inclined bed ensures quick chip evacuation. The new CPMS (Campro Production Management System) represent the first step in smart manufacturing.
Working Area
Swing over bed: 26.74”
Swing over cross slides:16.35”
Maximum turning diameter: 15.74”
Maximum turning length: 20.47”
Travel
X Axis Travel: 8.66”
Y Axis Travel: 3.93”
Z Axis Travel: 24.8”
Rapid Traverse: 787 / 393 / 945 IPM
Spindle
Spindle Motor: 15 / 20 HP
Maximum Speed: 4,200 RPM
Hydraulic Chuck: 10”
Spindle Nose: A2-6
Hole Through Draw Tube: 2.05”
Turret
Tooling style: BMT-55
Turret Type: 12 – Servo driven
One Axial and one Radial BMT live holder included
Tailstock
Quill Diameter: 3.15”
Tailstock Travel: 1.81”
Quill Travel: 4.72”
Quill Taper: MT - #4
General
Floor Space Required (W X D): 151.14” X 76.77”
Height: 70.28”
Machine Weight: 9,150 LBS
Standard Power Source: 205-235 Volts / 3 Phase / 60HZ
Power Capacity Minimum: 57 Amps
Control Specifications – Fanuc OiM-F Conversational Control
8.4” color LCD screen Color graphics
Simultaneous Controlled Axis
Least input Increment on X and Z is .001 mm Least command increment on X and Z is .001mm Inch/Metric Conversion (G20/G21)
Interlock on All Axes Machine Lock on All Axes Emergency Stop
Stored Stroke Check 1, 2, 3, Mirror Image
Backlash Compensation
Unexpected disturbance torque detection Stored pitch compensation
Automatic Operation (Memory) MDI Operation
Search Function (Sequence, Program) Program restart
Dry Run Single Block Buffer Register
Manual Handle Interrupt
Manual Jog Feed (Rapid, Jog, Handle) Manual Handle Feed Rate (x1, x10, x100)
Feed Command (F Code Feedrate Direct Command) Feedrate Override 0-200% (10% Unit)
Jog feed 0-5,000 mm/min (197 ipm)
Rapid traverse override (F0, F25%, F50%, F100%) Override Cancel
Rapid Traverse Bell-Shaped Acceleration/Deceleration Block Skip
Exact Stop Mode / Exact Stop (G61/G09) Dwell (G04)
Helical Interpolation Threading/Synchronous Feed Manual Reference Point Return 1st Reference Point Return
G28 Reference Point Return Check
G27 2nd Reference Point Return
G30 3rd and 4th Reference Point Return
