Linear guideway vertical machining center for high-speed cutting Travels: 29.5" x 16.9" x 18.9"

The CNV-750 is designed for long-term high accuracy, and superior surface finishes. Classic manufacturing methods and ultra-rigid construction are combined with advanced technological features to provide exceptional value.

• Constructed with high quality meehanite cast iron and heat treated to relieve stress thereby assuring maximum rigidity and accuracy.
• The CNV-750 is equipped with high precision and heavy loading series linear guideways on all 3 axes. Automatic lubrication system for all linear guideways and ballscrews.
• The base is reinforced by “A” type rib layout to upgrade absorption capability of vibration and is constructed of a box type structure for excellent rigidity. The machine structure is designed via Finite Element Analysis (FEA) and advanced 3D software.

Capacity

X axis travel: 30”

Y axis travel:16.92”

Z axis travel: 18.89”

Spindle nose to table top: 3.93” – 22.83”

Column to spindle center: 19.09”

Table

Table Loading Area: 33.46” X 16.92”

Allowable Table Load: 660 lbs.

Table T Slots - width x slot spacing: .551” X 3.937” X 4”

Spindle

Spindle speed: 12,000 RPM

Spindle Motor, Max / Cont.: 15 / 10

Spindle taper: CAT 40 Big Plus

Spindle Driving Method: Belt Drive

Automatic Tool Changer

ATC type: Twin Arm Type

Tool Shank: CAT 40

Pull Stud: P-40T (45 Deg.)

Number of tools: 24

Max tool dia.: 3.15”

Max tool diameter (No Adjacent Tool): 5.1”

Max tool length: 9.8"

Max tool weight: 13.2 lbs.

Tool Change Time TOOL - TOOL: 2.5 sec.

Tool Change Time CHIP - CHIP: 6 sec.

Tool Selection: Random Bi-Directional

Feedrate

Rapid traverse rate: 1,181 IPM All Axes

Cutting feed rate: 393 IPM

Least Command Increment: .001 mm

Positioning accuracy: +/- .00020" (full stroke)

Repeatability: +/- .00008"

Slide Type: LM Guideways

General

Air Source Requirement: 85 – 115 PSI (3/8 ID Supply Hose)

Standard Power Source: 205-235 Volts / 3 Phase +/- 10%

Power capacity: 40 Amps Minimum

Floor space required (W x D X H): 89” X 106” in. X 104” in.

Machine weight: 7,260 lbs.

 STANDARD FEATURES

Fanuc 0i-MF Plus Control (Package B)

AI APC Contour Control

12,000 RPM Spindle (Belt Drive)

Powerful 15 hp (30 min) high torque spindle motor

Cartridge Spindle Design

CAT40 Big Plus Spindle

290 PSI CTS Prep Only

Spindle Air Blow

Rigid tapping

Custom Macro B (User Definable)

Twin Arm 20 Tool ATC

Tool Change Time (Tool To Tool) 2.5 sec.

Tool Change Time (Chip to Chip) 6.0 sec.

Program and data protection key switch

Massive One-piece Meehanite cast iron bed

Chip Auger

4th Axis Prep (no amplifier)

Chip Flushing System

Double Anchored, Pretensioned Ballscrews

Fast 1,181 IPM Rapid Traverse rate

Full enclosure splash guard

Flood coolant with large coolant tank

Work light (2)

Operator call lamp (red, yellow, green)

Spindle load meter

Assembly and operation tools

Auto Power Off

Heat exchanger for Electrical Cabinet

Instruction manual, parts list, and electrical diagram

Fanuc operator and maintenance manuals

WARRANTY: Machine: One Year, Parts

WARRANTY: Control: Two Year, Parts & Labor

Linear guideway vertical machining center for high-speed cutting Travels: 33.4" x 20.3" x 20.3"

The CNV-850 is designed for long-term high accuracy, and superior surface finishes. Classic manufacturing methods and ultra-rigid construction are combined with advanced technological features to provide exceptional value.

• Constructed with high quality meehanite cast iron and heat treated to relieve stress thereby assuring maximum rigidity and accuracy.
• The CNV-850 is equipped with high precision and heavy loading series linear guideways on all 3 axes. Automatic lubrication system for all linear guideways and ballscrews.
• The base is reinforced by “A” type rib layout to upgrade absorption capability of vibration and is constructed of a box type structure for excellent rigidity. The machine structure is designed via Finite Element Analysis (FEA) and advanced 3D software.

Our counter balance system is equipped with a guide rail for increased stability, thus avoiding vibration during high feedrates and rapid traverse, this ensures machining accuracy.

 Capacity

X axis travel: 33.4”

Y axis travel: 20.3”

Z axis travel: 20.3”

Table Loading Area: 37.4” X 20.4”

Allowable Table Load: 1102 lbs.

Table T Slots - width x slot spacing: 0.7” x 5.0” X 3.9”

Spindle

Spindle nose to table top: 4.3” – 24.8”

Column to spindle center: 24.8”

Spindle taper: CAT 40 Big Plus

Spindle speed: 12,000 RPM

Spindle Driving Method: Belt Drive

Automatic Tool Changer

ATC type: Arm Type - Carousel

Number of tools: 24

Tool Shank: CAT 40

Max tool dia.: 3.1”

Max tool diameter (No Adjacent Tool): 5.9”

Max tool length: 9.8”

Max tool weight: 15 lbs.

Tool Selection: Random Bi-Directional Type

Motion

X and Y axis rapid traverse rate: 1,181 IPM All Axes

Z axis rapid traverse rate: 1,181 IPM All Axes

Cutting feed rate: 393 IPM

Slide Type: LM Roller Guideways

Least command increment: .001 mm,

Positioning accuracy: +/- .00020”

Repeatability: +/- .00008"

General

Floor space required (W x D X H): 115” X 88” in. X 105” in.

Machine weight: 11,023 lbs.

Standard Power Source Requirement - Fanuc: 2220V, 60HZ, 3 Phase +/- 10%

Power capacity: 40 Amps Minimum

Air Source Requirement: 85 – 115 PSI (3/8 ID Supply Hose)

STANDARD FEATURES

Fanuc Oi-MF Plus Control (Package B)

AI APC Contour Control

12,000 RPM Spindle (Belt Drive)

Powerful 15 hp (30 min) high torque spindle motor

Cartridge Spindle Design

CAT40 Big Plus Spindle

290 PSI CTS Prep Only

Spindle Air Blow

Rigid tapping

Custom Macro B (User Definable)

Twin Arm 24 Tool ATC

Tool Change Time (Tool To Tool) 2.5 sec.

Tool Change Time (Chip to Chip) 6.0 sec. * Portable Manual pulse generator

Program and data protection key switch

Massive One-piece Meehanite cast iron bed

Chip Auger

4th Axis Prep (no amplifier)

Chip Flushing System

Double Anchored, Pretensioned Ballscrews

Fast 1,181 IPM Rapid Traverse rate

Full enclosure splash guard

Flood coolant with large coolant tank

Work light (2)

Operator call lamp (red, yellow, green)

Spindle load meter

Assembly and operation tools

Auto Power Off

Heat exchanger for Electrical Cabinet

Instruction manual, parts list, and electrical diagram

    Fanuc operator and maintenance manuals

WARRANTY:   Machine:    One Year, Parts Only

                        Control:     Two Years, Parts & Labor

Linear guideway vertical machining center for high-speed cutting Travels: 33.4" x 20.3" x 20.41.3" x 21.2" x 20.4"

The CNV-1050 is designed for long-term high accuracy, and superior surface finishes. Classic manufacturing methods and ultra-rigid construction are combined with advanced technological features to provide exceptional value.

• Constructed with high quality meehanite cast iron and heat treated to relieve stress thereby assuring maximum rigidity and accuracy.
• The CNV-1050 is equipped with high precision and heavy loading series linear guideways on all 3 axes. Automatic lubrication system for all linear guideways and ballscrews.
• The base is reinforced by “A” type rib layout to upgrade absorption capability of vibration and is constructed of a box type structure for excellent rigidity. The machine structure is designed via Finite Element Analysis (FEA) and advanced 3D software.

 Capacity

X axis travel: 41.3”

Y axis travel: 21.2”

Z axis travel: 20.4”

Table Loading Area: 45.”2 X 20.4”

Allowable Table Load: 1320 lbs.

Table T Slots - width x slot spacing: 0.7” X 3.9” X 5

Spindle

Spindle nose to table top: 4.3” – 24.8”

Column to spindle center: 24.8”

Spindle taper: CAT 40 Big Plus

Spindle speed: 12,000 RPM

Spindle Driving Method: Belt Drive

Automatic Tool Changer

ATC type: Twin Arm Type

Number of tools: 24

Tool Shank: CAT 40 BIG +

Max tool dia.: 3.15”

Max tool diameter (No Adjacent Tool): 5.9”

Max tool length: 9.8"

Max tool weight: 15.4 lbs.

Tool Selection: Random Bi-Directional

Motion

X and Y axis rapid traverse rate:. 1,181 IPM All Axes

Z axis rapid traverse rate: 1,181 IPM All Axes

Cutting feed rate: 393 IPM

Slide Type: Box Ways

Slide Type: LM Guideways

Least command increment: 001mm

Positioning accuracy: .00020"

Repeatability: .00008"

General

Floor space required (W x D X H): 132” X 89” in. X 105.5” in.

Machine weight: 12,566 lbs.

Standard Power Source Requirement - Fanuc: 205-235 Volts / 3 Phase +/- 10%

Power capacity: 40 Amps Minimum

Air Source Requirement: 85 – 115 PSI (3/8 ID Supply Hose)

STANDARD FEATURES

Fanuc Oi-MF Control (Package B)

AI APC Contour Control

12,000 RPM Spindle (Belt Drive)

Powerful 15 hp (30 min) high torque spindle motor

Cartridge Spindle Design

CAT40 Big Plus Spindle

1000 PSI CTS Prep Only

Spindle Air Blow

Rigid tapping

Custom Macro B (User Definable)

Twin Arm 24 Tool ATC

Tool Change Time (Tool To Tool) 3.5 sec.

Tool Change Time (Chip to Chip) 7.0 sec. * Portable Manual pulse generator

Program and data protection key switch

Massive One-piece Meehanite cast iron bed

Chip Auger

4th Axis Prep (no amplifier)

Chip Flushing System

Double Anchored, Pretensioned Ballscrews

Fast 1,181 IPM Rapid Traverse rate

Full enclosure splash guard

Flood coolant with large coolant tank

Work light (2)

Operator call lamp (red, yellow, green)

Spindle load meter

Assembly and operation tools

Auto Power Off

Heat exchanger for Electrical Cabinet

Instruction manual, parts list, and electrical diagram

Fanuc operator and maintenance manuals

WARRANTY: Machine: One Year, Parts Only

Control: Two Years, Parts & Labor

Linear guideway vertical machining center for high-speed cutting Travels: 51.1" x  23.6" x 24.0"

The CNV-1050 is designed for long-term high accuracy, and superior surface finishes. Classic manufacturing methods and ultra-rigid construction are combined with advanced technological features to provide exceptional value.

• Constructed with high quality meehanite cast iron and heat treated to relieve stress thereby assuring maximum rigidity and accuracy.
• The CNV-1050 is equipped with high precision and heavy loading series linear guideways on all 3 axes. Automatic lubrication system for all linear guideways and ballscrews.
• The base is reinforced by “A” type rib layout to upgrade absorption capability of vibration and is constructed of a box type structure for excellent rigidity. The machine structure is designed via Finite Element Analysis (FEA) and advanced 3D software.

 Capacity

X axis travel: 51.1”

Y axis travel: 23.6”

Z axis travel: 24.0”

Distance from Spindle Nose to Table: 3.1” – 27.1”

Spindle

Spindle speed: 12,000 RPM (15,000 Optional)

Spindle Motor, Max / Cont.: 20 / 25

Spindle Taper Type: CAT 40 Big Plus

Spindle Driving Method: Belt Drive

Automatic Tool Changer

ATC type: Twin Arm Type

Tool Shank: CAT 40 BIG +

Pull Stud: P - 40T (45 Deg.)

Tool Storage Capacity: 24

Max tool dia.: 3.15”

Max tool diameter (Adjacent Pot Empty): 5.9”

Max tool length: 9.8"

Max tool weight: 15.4 lbs.

Tool Change Time TOOL - TOOL: 3.5 sec.

Tool Change Time CHIP - CHIP: 7.0 sec.

Tool Selection: Random Bi-Directional Type

Feedrate

Rapid Traverse Feedrate: 1,181 IPM X and Y

Rapid Traverse Feedrate: 945 IPM Z

Cutting Feedrate: 394 IPM

Least command increment: 001mm

Positioning accuracy: .00020"

Repeatability: .00008"

Power

Air Source Requirement: 85 – 115 PSI (3/8 ID Supply Hose)

Standard Power Source: 220V, 60HZ, 3 Phase +/- 10%

Power capacity: 50 Amps Minimum

Floor Plan (W x D): 132” X 100” in.

Height: 111" in

STANDARD FEATURES

Fanuc Oi-MF PLUS Control (Package B)

AI APC Contour Control

12,000 RPM Spindle

Powerful 25 hp (30 min) high torque spindle motor

Cartridge Spindle Design

CAT40 Big Plus Spindle

290 PSI Coolant Through Spindle - Prep Only

Spindle Air Blow

Rigid tapping

Custom Macro B (User Definable)

Twin Arm 24 Tool ATC

Tool Change Time (Tool To Tool) 3.5 sec.

Tool Change Time (Chip to Chip) 7.0 sec. * Portable Manual pulse generator

Program and data protection key switch

Massive One-piece Meehanite cast iron bed

Chip Auger

Chip Flushing System

Double Anchored, Pretensioned Ballscrews

Fast 1,181 IPM Rapid Traverse rate

Full enclosure splash guard

Flood coolant with large coolant tankWork light (2)

Operator call lamp (red, yellow, green)

Spindle load meter

Assembly and operation tools

Auto Power Off

Heat exchanger for Electrical Cabinet

Instruction manual, parts list, and electrical diagram

Fanuc operator and maintenance manuals

Ultra rigid box way VMC for heavy cutting and long term accuracy Travels: 41.3" x 20.8" x 30.7"

CPV-1050B

The CPV Box Way Series of Vertical Machining Centers is designed for heavy cutting, long-term high accuracy, and superior surface finishes. Classic manufacturing methods and ultra rigid construction are combined with advanced technological features to provide exceptional value. Constructed with high quality Meehanite cast iron and heat treated to relieve stress thereby assuring maximum rigidity and accuracy. ​

• Box ways on all 3 axes greatly upgrades stability and dampening capability.
• Automatic lubrication unit with intelligent pressure failure detection function provides reliable supply for saving cost and for environmental protection.
• Oil-coolant separation design which meets the environment protection requirements allows centralized collection for all way oil.

Standard Features:

Balanced 12,000 RPM Spindle with 6000 BTU spindle oil cooler for High Speed Machining.

Hardened and Ground C3 Double Nut Ballscrews (Ø40 mm) are pre-tensioned to minimize backlash, provide high precision movement, and reduce heat deformation on all axes.

All solid ways are coated with high grade Turcite-B. Hardened and ground slideways give an extra 40% wear resistance.

2 Solid Box Ways are on a one-piece base instead of two supporting ways connected to the main base, which provides more rigidity under heavy machining.

Main frame is made of Meehanite casting for superior rigidity

Capacity

X axis travel: 42"

Y axis travel: 20.9"

Z axis travel: 30.7"

Table Loading Area: 41.3” x 20.9”

Allowable Table Load: 2200 pounds

Table T Slots - width x slot spacing: .708” x 3.937” – (5)

Spindle

Spindle nose to table top: 3.9” – 34.6”

Spindle nose diameter: 2.8"

Column to spindle center: 23.2"

Spindle taper: CAT 40 Big Plus

Spindle speed: 12,000 RPM

A.C. spindle motor (30 min.): 20 HP

Spindle torque (30 min): 132 ft-lbs.

Spindle Driving Method: Belt Drive

Automatic Tool Changer

ATC type: Twin Arm Type

Number of tools: 24

Tool Shank: CAT 40

Max tool dia.: 3.1”

Max tool diameter (No Adjacent Tool): 5.9”

Max tool length: 9.8"

Max tool weight: 15.4 lbs.

Tool Selection: Random Bi-Directional

Motion

X and Y axis rapid traverse rate: 1,181 IPM

Z axis rapid traverse rate: 1,181 IPM

Cutting feed rate: 393 IPM

Slide Type: Box Ways

Least command increment: 001mm

Positioning accuracy: +/- .00020" (full stroke)

Repeatability: +/- .00008"

General

Floor space required (W x D X H): 125" x 96" X 120”

Machine weight: 13,700 lbs.

Standard Power Source Requirement - Fanuc: 205-235 Volts / 3 Phase/60HZ

Power capacity: 53 Amps Minimum

Air Source Requirement: 85 – 115 PSI

Ultra rigid box way VMC for heavy cutting and long term accuracy Travels: 43.3" x 24.4" x 23.6"

CPV-1100B

• Constructed with high quality meehanite cast iron and heat treated to relieve stress thereby assuring maximum rigidity and accuracy.
• Box ways on all 3 axes greatly upgrades stability and dampening capability.
• Automatic lubrication unit with intelligent pressure failure detection function provides reliable supply for saving cost and for environmental protection.
• Oil-coolant separation design which meets the environment protection requirements allows centralized collection for all way oil.

Standard Features:

Constructed with high quality meehanite cast iron and heat treated to relieve stress thereby assuring maximum rigidity and accuracy.

Box ways on all 3 axes greatly upgrades stability and dampening capability.

Automatic lubrication unit with intelligent pressure failure detection function provides reliable supply for saving cost and for environmental protection.

Oil-coolant separation design which meets the environment protection requirements allows centralized collection for all way oil.

Capacity

X axis travel: 43.3”

Y axis travel: 24.4”

Z axis travel: 23.6”

Table Loading Area: 47.2” x 23.6”

Allowable Table Load: 2,425 pounds

Spindle

Spindle nose to table top: 4.7” – 28.3”

Column to spindle center: 26.3”

Spindle taper: CAT 40 Big Plus

Spindle speed: 12,000 RPM

A.C. spindle motor (30 min.): 20 HP

Spindle torque (30 min): 132 ft-lbs.

Spindle Driving Method: Belt Drive

Automatic Tool Changer

ATC type: Twin Arm Type

Number of tools: 24

Tool Shank: CAT 40

Max tool dia.: 3.1”

Max tool diameter (No Adjacent Tool): 5.9”

Max tool length: 9.8"

Max tool weight: 15.4 lbs.

Tool Selection: Random Bi-Directional

Motion

X and Y axis rapid traverse rate: 787 IPM

Z axis rapid traverse rate: 787 IPM

Cutting feed rate: 393 IPM

Slide Type: Box Ways

Least command increment: .001mm

Positioning accuracy: +/- .00020" (full stroke)

Repeatability: +/- .00008"

General

Floor space required (W x D X H): 131" x 106" X 113”

Machine weight: 14,330 lbs

Standard Power Source Requirement - Fanuc: 205-235 Volts / 3 Phase/60HZ

Power capacity: 53 Amps Minimum

Air Source Requirement: 85 – 115 PSI

Ultra rigid box way VMC for heavy cutting and long term accuracy Travels: 55.1" x 29.5" x 27.5"

CPV-1400B - 50 Taper

• Constructed with high quality meehanite cast iron and heat treated to relieve stress thereby assuring maximum rigidity and accuracy.
• Box ways on all 3 axes greatly upgrades stability and dampening capability.
• Automatic lubrication unit with intelligent pressure failure detection function provides reliable supply for saving cost and for environmental protection.
• Oil-coolant separation design which meets the environment protection requirements allows centralized collection for all way oil.

Standard Features:

Balanced 6,000 RPM Spindle with spindle oil cooler 6000 BTU for High Speed Machining.

Hardened and Ground class C3 precision double-nut ballscrews (Ø40 mm) are pre-tensioned to minimize backlash, provide high precision movement, and reduce heat deformation on all axes.

Precision scraping on both bonded Turcite-B and cast iron surfaces helps to reduce wearing out, maintaining operation accuracy.

Hardened and ground slideways give an extra 40% wear resistance.

Capacity

X axis travel: 55.1"

Y axis travel: 29.5"

Z axis travel: 27.5"

Table Loading Area: 61" X 27.5"

Allowable Table Load: 3,968 lbs

Table T Slots - width x slot spacing: 0.7” x 5.0” x 3.9"

Spindle

Spindle nose to table top: 5.9" – 33.5"

Spindle nose diameter: 33.4"

Column to spindle center: 33.4"

Spindle taper: CAT 50 Big Plus

Spindle speed: 6,000 RPM

A.C. spindle motor (30 min.): 25 HP

Spindle torque (30 min): 384 ft-lbs

Spindle Driving Method: Geared Head Spindle

Automatic Tool Changer

ATC type: Twin Arm Type

Number of tools: 24

Tool Shank: CAT 50

Max tool dia.: 4.3”

Max tool diameter (No Adjacent Tool): 7.8”

Max tool length: 11.8”

Max tool weight: 33 lbs.

Tool Selection: Random Bi-Directional

Motion

X and Y axis rapid traverse rate: 590 IPM

Z axis rapid traverse rate: 472 IPM

Cutting feed rate: 393 IPM

Slide Type: Box Ways

Least command increment: .001mm

Positioning accuracy: +/- .00020" (full stroke)

Repeatability: +/- .00008"

General

Floor space required (W x D X H): 152" X 127.8" X 118"

Machine weight: 25,353 lbs.

Standard Power Source Requirement - Fanuc: 205-235 Volts / 3 Phase/60HZ

Power capacity: 83 Amps Minimum

Air Source Requirement: 85 – 115 PSI (3/8 ID Supply Hose)

Ultra rigid box way VMC for heavy cutting and long term accuracy Travels: 62.9" x 32.6" x 27.5"

CPV-1600B - 50 Taper

MACHINE FEATURES

• Constructed with high quality meehanite cast iron and heat treated to relieve stress thereby assuring maximum rigidity and accuracy.
• Box ways on all 3 axes greatly upgrades stability and dampening capability.
• Automatic lubrication unit with intelligent pressure failure detection function provides reliable supply for saving cost and for environmental protection.
• Oil-coolant separation design which meets the environment protection requirements allows centralized collection for all way oil.

Standard Features:

Balanced 6,000 RPM Spindle with spindle oil cooler 6000 BTU for High Speed Machining.

Hardened and Ground class C3 precision double-nut ballscrews (Ø40 mm) are pre-tensioned to minimize backlash, provide high precision movement, and reduce heat deformation on all axes.

Precision scraping on both bonded Turcite-B and cast iron surfaces helps to reduce wearing out, maintaining operation accuracy. Hardened and ground slideways give an extra 40% wear resistance.

Capacity

X axis travel: 62.9"

Y axis travel: 32.6"”

Z axis travel: 27.5"

Table Loading Area: 70.8" X 31.4"

Allowable Table Load: 4,409 lbs

Table T Slots - width x slot spacing: .866” x 4.921” x 5

Spindle

Spindle nose to table top: 5.9" – 33.5"

Column to spindle center: 33.4"

Spindle taper: CAT 50 Big Plus

Spindle speed: 6,000 RPM

A.C. spindle motor (30 min.): 25 HP

Spindle torque (30 min): 384 ft-lbs

Spindle Driving Method: Geared Head Spindle

Automatic Tool Changer

ATC type: Twin Arm Type

Number of tools: 24

Tool Shank: CAT 50

Max tool dia.: 4.3”

Max tool diameter (No Adjacent Tool): 7.8”

Max tool length: 11.8”

Max tool weight: 33 lbs.

Tool Selection: Random Bi-Directional

Motion

X and Y axis rapid traverse rate: 590 IPM

Z axis rapid traverse rate: 472 IPM

Cutting feed rate: 393 IPM

Slide Type: Box Ways

Least command increment: .001mm

Positioning accuracy: +/- .00020" (full stroke)

Repeatability: +/- .00008"

General

Floor space required (W x D X H): 169" X 127.8" X 126"

Machine weight: 33,069 lbs.

Standard Power Source Requirement - Fanuc: 205-235 Volts / 3 Phase/60HZ

Power capacity: 83 Amps Minimum

Air Source Requirement: 85 – 115 PSI (3/8 ID Supply Hose)

Ultra rigid box way VMC for heavy cutting and long term accuracy Travels: 86.6" x 40.1" x 31.4"

CPV-2200B - 50 Taper

MACHINE FEATURES ​

• Constructed with high quality meehanite cast iron and heat treated to relieve stress thereby assuring maximum rigidity and accuracy.
• Box ways on all 3 axes greatly upgrades stability and dampening capability.
• Automatic lubrication unit with intelligent pressure failure detection function provides reliable supply for saving cost and for environmental protection.
• Oil-coolant separation design which meets the environment protection requirements allows centralized collection for all way oil.

Capacity

X axis travel: 86.6"

Y axis travel: 40.1"

Z axis travel: 31.4"

Table Loading Area: 94.4" x 40.1"

Allowable Table Load: 6,613 lbs

Spindle

Spindle nose to table top: 7.8" - 39.3"

Column to spindle center: 41.3"

Spindle taper: CAT 50 Big Plus

Spindle speed: 6,000 RPM

A.C. spindle motor (30 min.): 25 HP

Spindle torque (30 min): 384 ft-lbs

Spindle Driving Method: ZF Gearbox

Automatic Tool Changer

ATC type: Twin Arm Type

Number of tools: 24

Tool Shank: CAT 50

Max tool dia.: 4.3” (110 MM)

Max tool diameter (No Adjacent Tool): 7.8” (200 MM)

Max tool length: 11.8” (300 MM)

Max tool weight: 33 lbs. (15 KG)

Tool Selection: Random Bi-Directional

Motion

X and Y axis rapid traverse rate: 472 IPM

Z axis rapid traverse rate: 393 IPM

Cutting feed rate: 393 IPM (10 m/min)

Slide Type: Box Ways

Least command increment: .001mm

Positioning accuracy: +/- .00020" (full stroke)

Repeatability: +/- .00008"

General

Floor space required (W x D X H): 231” x 156” X 136”

Machine weight: 48,500 lbs

Standard Power Source Requirement - Fanuc: 205-235 Volts / 3 Phase/60HZ

Power capacity: 83 Amps (30 KVA)

Air Source Requirement: 85 – 115 PSI (3/8 ID Supply Hose)

Double Column Bridge Mill Travels: 86" x 62" x 29"

PV-2216
